The machine adopts an inflow feeding mode. The material flows into the hopper and is lifted to the top by the plate chain. The material is discharged by itself under the action of material gravity. Chain is a high-strength plate chain made of high-quality alloy steel. It is wear-resistant and reliable. The drive part adopts hard tooth surface reducer.

Automatic hoist product introduction:

The automatic hoist is a lifting equipment of plate-chain type and gravity-induced unloading. Motor assembly line is suitable for vertical transportation of powdery, granular, small pieces of grinding or non-grinding materials, such as raw materials, cement, coal, limestone, dry clay, clinker, etc.

Automatic hoist is a new hoisting product developed by introducing advanced technology from abroad. Powder coating line automatic hoist is applied in various industrial countries. Because of energy saving and high efficiency, automatic hoist is gradually replacing HL type chain hoist. The automatic hoist is an inflow feeding machine. The material flows into the hopper and is lifted to the top by the plate chain. The material is discharged by itself under the action of material gravity. The main technical parameters meet the Ministry of Machinery Standards (JB3926-85). The hoist is suitable for the vertical transportation of medium, large and polished materials (such as limestone, cement clinker, gypsum, lump coal), and the material temperature is controlled below 250 C.

Folding main structure

The automatic hoist is composed of running parts, driving device, upper device, middle casing and lower device.

Operating components - consisting of hopper and special plate chain, automatic hoist and single-row chain underneath.

Driving device - Drive by multiple driving combinations (depending on the actual needs of users). The driving platform is equipped with overhaul racks and railings. There are two kinds of driving devices, left and right.

The upper device is equipped with rails (double-row chains), backstops and discharge outlets equipped with anti-recycling rubber plates.

Mid-section - Some mid-sections are equipped with rails (double chains) to prevent chains from swinging.

Bottom device - automatic tensioning device is installed.
